Fasco F1B 14-16 14 series Upholstery Stapler

Description

The Fasco F1B 14-16 14 series upholstery Stapler is ready to be dispatched by nationwide next day delivery.

Designed with long and narrow nose for excellent job visibility.

One hand latch for fast reloading time.

Magazine without any welded parts makes maintenance and helps to extend durability of tool.

Extended life driver pin blade for robust industrial environments and durability.

Securall Fastenings stocks spare parts for the Fasco F1B 14-16 14 series Upholstery Stapler.

Securall Fastenings stocks 14 series upholstery staples for the Fasco 14 series upholstery stapler.

Rubber comfort grip reduces operator fatigue after long hours usage.

Rear exhaust with muffler keeps sound to a minimum.

Bottom quick loading magazine allows for high speed stapling and keeps out the dirt.

Technical specifications:

Tool type:  fine wire stapler
Magazine Capacity:  180 staples
Fastener length:  6 – 16mm
Height:  157mm
Width:  42mm
Length:  218mm
Weight:  0.775 kg
Pressure 4 – 7 bar (60 – 100 psi)
Air Consumption per cycle:  0.37l at 6.2bar (90psi)
Actuation system:  single shot
Loading:  bottom loading
Noise value:  (EN 12549+A1 : 2008, EN ISO 4871 : 2009)

• LWA,1s: 89.02 dB (A) – KWA,1s, 2.5
• LpA,1s: 79.70 dB (A) – KpA,1s, 2.5

Applications:

upholstery, boat building, construction, general tacking, carpets, underlay,remodeling, re-upholstery, construction, garden furniture, moldings, joinery
